25Foot Aluminium Boats Technology Specification

Dimensions

◆ Overall length: 7.5m

◆ Maximum length: 8.25m / 27 ft

◆ Overall width: 2.45m

◆ Depth: 1.45m

◆ Side plate thickness: 4 mm

◆ Bottom plate thickness: 6 mm

◆ Transom thickness: 6mm

◆ Transom height: 25''

⚙️ Power and performance

◆ Minimum recommended power: 200 horsepower

◆ Maximum power: 300 horsepower

⚖️ Weight

◆ Hull weight: 1670kg

Notice: When you install the maximum horsepower engine, please confirm with manufacturer.

25Foot Aluminum Fishing Boats Features

⚓ Hardcore configuration · Designed for the ultimate experience

▌ Highlights of hull functions

✓ Professional fishing system:

Integrated fishing rod rack, quick access without tangling

Sealed moisture-proof bait box, partitioned storage is more efficient

Fish cutting board, easy to clean without dirtying the boat

✓ Smart space design:

Foldable bench at the stern (with cushion)

Hidden storage compartment, freeing up more space for activities

✓ Strong towing capacity:

Reinforced stern trailer hook, enhance the stability of the trailer

✓ Customization service:

Layout/color matching/accessories modular selection

Support exclusive customization of corporate logo.

▌ Black technology of aluminum hull

⚡ Corrosion resistance:

Tested on water, universal in sea areas

⚡ Lightweight and low consumption:

40% lighter than FRP boats, 25% lower fuel consumption

⚡ Win-win in load and speed:

Hull rigidity increased by 50%, load capacity up to 2.5 tons

Wave-breaking bottom design, 18% higher top speed

⚡ Zero maintenance advantage:

No anti-corrosion coating required, 10 years of free overhaul

25Foot Aluminum Fish Boat Standard & Optional Accessories

25Foot Aluminum Boats Safety operation & Maintenance

️ Safe sailing · Long-lasting like new

Safety operation specifications

▌ Inspection before sailing

✓ Power system: Check fuel quantity (300L aluminum tank), battery voltage, bilge pump status

✓ Hull structure: Confirm that the stern trailer hook is locked and there are no sharp objects left on the deck

✓ Safety device: Anchor light/sidelight function test, life jackets are equipped according to the number of passengers

▌ Passenger safety guidelines

⚠️ Overloading is prohibited: Maximum load ≤2500kg (including equipment/cargo)

⚠️ Fixed items during sailing: Fishing rod racks/bait boxes need to be locked to prevent tipping

⚠️ Speed limit in bad weather: ≤15 knots when wave height is >1 meter

▌ Emergency response

➤ Water inflow alarm: start the bilge pump immediately and check the status of the sealed compartment

➤ Power failure: release the emergency anchor

➤ Personnel falling into the water: start the SOS signal (one-button trigger on the control panel)

Maintenance guide

▌ Daily cleaning

✓ Hull flushing: flush with fresh water after each use of seawater to prevent salt crystal corrosion

✓ Deck maintenance: clean the patterned aluminum plate with a soft brush, and strong acid is prohibited

✓ Drainage system: clear the bilge pump filter every month and check the flushing pump pressure

▌ Hull protection

⚡ Anti-corrosion treatment: check the welding points every quarter and spray special antioxidants for aluminum alloys

⚡ Bump repair: minor scratches on the side panels can be filled with epoxy resin

▌ System maintenance

➤ Power system: change engine oil every 50 hours, 300 hp models require additional coolant inspection

➤ Hydraulic options: regularly check steering fluid level, replace low-temperature hydraulic oil in winter

➤ Electrical equipment: moisture-proof treatment of battery box, annual insulation test of fish light circuit

▌ Seasonal maintenance

❄️ Winter storage: empty fuel tank residual liquid, disassemble EVA floor to prevent deformation

☀️ Summer protection: hardtop T-type option is recommended to install sunshade to prevent UV aging

Professional service tips

✓ Hull rigidity inspection every 2 years (focus: 6mm welding seams)

✓ It is recommended to use original preservatives/hydraulic oils, compatible with aluminum alloy materials

✓ Customized accessories (such as Bluetooth speakers) require separate waterproof maintenance
