21 FOOT SPEED YACHT TECHNICAL PARAMETER

Hull parameters

Total length: 6.3 meters | Beam: 2.43 meters

Depth: 0.91 meters        | Draft: 0.43 meters

Unladen weight: 800kg  | Maximum passenger capacity: 8 people

⚙️ Power system

• Recommended configuration: single outboard engine 90-200 horsepower

• Control response: maximum speed can reach 30-40 knots (depending on horsepower configuration)

Note: Before installing the maximum horsepower engine, please contact the factory first, this is very important for the boat.

21 FOOT SPEED BOAT FEATURES

Product Features

Excellent performance

• Golden size: 6.3 meters long × 2.43 meters wide, 800kg lightweight hull, spacious passenger capacity for 8 people

• Powerful power: suitable for 90-200 horsepower single external engine, fast response, control like the wind

• Stable and durable: vacuum adsorption process creates 8-14mm fiberglass hull, impact resistance, corrosion resistance, and 30% increase in strength

Ingenious craftsmanship

• Vacuum adsorption technology: hull has no bubbles, zero gaps, more compact structure, and lighter sailing

• Five-year warranty commitment: fiberglass hull market reputation certification, worry-free quality

✨ Core advantages

• Lightweight design: low fuel consumption, high speed, both economic and performance

• Super corrosion resistance: no fear of seawater erosion, durable

21FOOT FIBERGLASS SPEED YACHT STANDARD AND OPTIONAL ACCESSORIES

Standard accessories

1. Safety protection

Rubbing Strake

Sidelight

U-shaped Ring at Bow

2. Hull and structure

Front Cabin

Transom

Circular Inspection Cover

3. Driving and control

Windscreen

Rail

Cable Conduit

4. Functional components

Battery Box

Hinges (12pcs)

Buckles (6pcs)

5. Warning and communication

Stern Horn (4pcs)

6. Drainage system

Bilge Pump

✨ Optional accessories

1. Practical extension

Trailer

Foldable Anchor

Fender

2. Control upgrade

Hydraulic Steering System

3. Comfort and convenience

Passenger seat

Gangway ladder

Cushion

4. Endurance enhancement

Customized fuel tank

21FOOT SPEED FIBERGLASS BOAT OPERATION AND SAFETY

⚠️ Operation precautions

1. Inspection before sailing

• Confirm that there is enough fuel and oil, and there is no abnormality in the external engine power system.

• Check that the life-saving equipment (life jackets, fire extinguishers, signal lights) is complete and available.

• Ensure that there are no cracks in the hull and no water in the bilge.

2. Crew safety

• No more than 8 passengers, avoid overloading.

• All passengers wear life jackets during navigation, and children need special care.

• No sailing in bad weather (strong winds, heavy rain).

3. Navigation operation

• Preheat the engine at low speed after starting, and avoid rapid acceleration.

• Drive carefully in shallow water areas to prevent the propeller from touching the bottom and being damaged.

• Slow down when turning, and avoid tilting due to sharp turns.

4. Mooring and storage

• Tighten the rope when docking to avoid collision with the hull.

• Long-term storage needs to be covered and dustproof, and placed in a cool and dry place.

• Drain the engine cooling water in winter to prevent freezing and rust.

️ Safety repair and maintenance guide

1. Regular maintenance

• Engine maintenance: change the engine oil every 50 hours, check the filter and transmission system every 100 hours.

• Hull inspection: check the surface of the FRP hull every month, and repair scratches or cracks in time.

• Electrical system: regularly check the battery power and line waterproofness to avoid short circuits.

2. Cleaning and care

• Flush the hull with fresh water after each use to remove salt and silt.

• Use special wax to maintain the surface of the FRP to delay aging.

• Keep the deck drain holes unobstructed to prevent water corrosion.

3. Key protection

• Anti-corrosion treatment: Apply anti-rust grease to metal parts (screws, brackets).

• Sealing guarantee: replace the hatch and porthole sealing strips every year to ensure waterproofness.

• Structural reinforcement: professionally test the stability of the vacuum adsorption structure inside the hull every 2 years.

4. Emergency treatment

• In case of hull damage: immediately activate the drainage pump and dock nearby.

• Engine failure: turn off the power, anchor and wait for rescue.

• Fire risk: quickly use a fire extinguisher and evacuate the passengers.
